Hydraulic cylinder Ts100.50.250.01.6 is used in the attachment of HTZ tractors and is designed to convert the energy of the working fluid flow into mechanical force, providing lifting and lowering of the attachment.
The hydraulic cylinder is double-acting and can be used both in the old-style hitch and in the new type hitch (Euro hook hitch) with two hydraulic cylinders. It has a sleeve (piston) diameter of 100 mm, a rod diameter of 50 mm and a rod stroke of 250 mm, which ensures high traction force and reliable operation with various agricultural equipment.
The use of two hydraulic cylinders allows you to increase the lifting capacity of the attachment and work effectively with heavier units. For maintenance and repair of the hydraulic cylinder, appropriate repair kits are available.
Used on tractors HTZ T-150K, T-151K, T-156, HTZ-17221, HTZ-159K, HTZ-242K, HTZ-245K, HTZ-248K, HTZ-249K and other models with a similar design of the attachment.
The hydraulic cylinder is double-acting and can be used both in the old-style hitch and in the new type hitch (Euro hook hitch) with two hydraulic cylinders. It has a sleeve (piston) diameter of 100 mm, a rod diameter of 50 mm and a rod stroke of 250 mm, which ensures high traction force and reliable operation with various agricultural equipment.
The use of two hydraulic cylinders allows you to increase the lifting capacity of the attachment and work effectively with heavier units. For maintenance and repair of the hydraulic cylinder, appropriate repair kits are available.
Used on tractors HTZ T-150K, T-151K, T-156, HTZ-17221, HTZ-159K, HTZ-242K, HTZ-245K, HTZ-248K, HTZ-249K and other models with a similar design of the attachment.
- Hydraulic cylinders / Shock absorbers
-
Working diameter 250 mm
-
Rod diameter 50 mm
-
Sleeve (piston) diameter 100 mm
-
Type двухстороннего действия
-
Chassis type колесный / гусеничный
-
Applicability by brand ХТЗ
-
Number of uses in a unit/technique 2 pcs
-
Installation location навесное устройство
-
Catalog number Ц100.50.250.01.6
-
Node гидравическая система
