Lifting arms (the so-called “horns”) are important parts of the new type of linkage (EURO-hook type linkage) of HTZ tractors. Installed as a kit:
-
172.56.151-01 - left,
-
172.56.151 - right.
They are mounted on the lever shaft 151K.56.018 (splined shaft) together with the rod lever 120.56.015, which ensures synchronous operation of the linkage elements. Lifting levers serve to transfer force from hydraulic cylinders to attachments and are involved in raising and lowering mounted agricultural machinery.
Used on HTZ tractors:
-
T-150, T-151K, T-151,
-
HTZ-17221, HTZ-242, HTZ-248
and others equipped with a new type of hook hitch.
-
Chassis type колесный / гусеничный
-
Applicability by brand ХТЗ
-
Number of uses in a unit/technique комплект 2 pcs
-
Installation location вал рычагов / шлицевой вал
-
Catalog number 172.56.151-01 / 172.56.151
-
Node навесное устройство
