The upper link 172.56.029-1 is an element of a new EURO hook linkage designed for connecting attachments to the tractor and adjusting its vertical position. It is installed in the central part of the attachment and acts as a central screw, providing precise adjustment of the angle of inclination of the attachments.
On one side, the rod is equipped with a hook part, which is equipped with a hinge 180.56.157, which ensures mobility and stability of the connection during operation of the implements. On the other hand, the rod is fixed with a pin to the head 180.56.139, which guarantees the strength and reliability of the connection.
The design of the traction is reinforced and is designed for significant traction loads and vibrations that occur during the operation of attachments. Thanks to the threaded adjustment mechanism, the operator can precisely change the length of the rod to level the implements in the horizontal plane.
It is used as part of the EURO hitch of the new model of tractors HTZ-17221, HTZ-17222, HTZ-242, HTZ-248, and can also be installed when modernizing the mounted systems of tractors T-150, T-151, T-156 and other machines of the HTZ family.
