The brace link 77.60.164-1A is used in the hitch of HTZ tractors and is an element connecting the brace to the lifting arms of the hitch mechanism.
The part is part of the brace assembly assembly 150.56.039. The earring is connected to the brace body using the brace earring pin 77.60.165, which is fixed with a cotter pin 6.3x40 and connects it to the upper brace screw 150.56.185. A small lever pin 77.60.168-1 (part of the lock assembly 150.56.035-1) passes through the main hole of the shackle, providing connection with the left lifting lever 150.56.151A or the right lifting lever 150.56.152A.
Installed in the amount of 2 pieces per tractor.
It is used on tractors HTZ T-150, T-150K, T-151, T-151K, T-156 and other equipment with a similar design of attachments.
The part is part of the brace assembly assembly 150.56.039. The earring is connected to the brace body using the brace earring pin 77.60.165, which is fixed with a cotter pin 6.3x40 and connects it to the upper brace screw 150.56.185. A small lever pin 77.60.168-1 (part of the lock assembly 150.56.035-1) passes through the main hole of the shackle, providing connection with the left lifting lever 150.56.151A or the right lifting lever 150.56.152A.
Installed in the amount of 2 pieces per tractor.
It is used on tractors HTZ T-150, T-150K, T-151, T-151K, T-156 and other equipment with a similar design of attachments.
-
Chassis type колесный / гусеничный
-
Applicability by brand ХТЗ
-
Number of uses in a unit/technique 2 pcs
-
Installation location раскос / рычаг подъемный
-
Catalog number 77.60.164-1А
-
Node навесное устройство
