Gear Shift Lever Assembly with Switch 150.37.075-1

Gear Shift Lever Assembly with Switch 150.37.075-1 is used in the transmission of HTZ crawler tractors and is designed to control gear shifting, as well as the operation of the transmission interlock mechanism and electrical switch.

The assembly is mounted on Transmission Housing Cover 150.37.160-2A (part of Transmission Cover Assembly 150.37.013-1) using Gasket 150.37.227, which provides a reliable oil-tight seal.

The 150.37.075-1 assembly includes: Gear Shift Lever 150.37.170, Handle A13.04.000A, Clamp XS-95Ts15Hr, Fork A5.24.244, Nut M12.6.01.12, Interlock Rod 150.37.050, Boot 54.37.489, Thrust Bushing A37-60, 6×32 Rivet, Cap Spring 54.37.462, Cap A37-63, Gear Shift Lever Housing 150.37.169-1, Set Screw 125.37.270, 8.65G.05 and 12.65G.05 Washers, Pin 74.37.460, Locking Bolt 150.37.472, Bolt M10-6g×50.66.019, 10.65G.05 Washer, Cotter Pin 2×16.001, Pin A5.24.243, Interlock Shaft 150.37.287, O-Ring 016-020-25-2-2, Clamp Bolt 150.37.597, Clamp 150.37.595, Insert 74.37.485, Adjusting Shim 74.37.476, VK403-3716000 Switch, Bushing 150.37.596, Lock Plate 150.37.594, and Bolt M8-6g×12.66.019.

The assembly is supplied as a complete mechanism combining the gear shift lever, transmission interlock mechanism, and electrical switch. This integrated design ensures precise gear selection, secure lever positioning, and reliable operation of the transmission interlock system. The condition of this assembly has a direct impact on driving comfort and the service life of the transmission.

The assembly is used on HTZ T-150G crawler tractors and other machines equipped with the same transmission design.
