Filter element 761-00-00-00 (oil filter) is a replaceable element for fine oil purification that protects units from mechanical impurities and wear products. It is used in several units of KhTZ tractors at once, which makes it a universal and sought-after component.
In the gearbox of tractors T-150, HTZ-17221 and their modifications, the filter element is installed inside the filter housing 151.37.014-1A and works in tandem with the pipe 151.37.015-3, directing the oil flow. In the hydraulic system, the same element is part of the hydraulic tank filter 150.40.080-1 assembly, performing a similar function of cleaning the working fluid.
Due to its design, filter 761-00-00-00 is also used on MTZ-80/82 tractors, where it is mounted in the hydraulic unit housing, forming a hydraulic tank filter assembly A28.04.00.000-A.
It is characterized by a high degree of filtration, reliability and durability, which is confirmed by many years of operation in various climatic and load conditions.
-
Applicability by brand ХТЗ / МТЗ
-
Catalog number 761-00-00-00
-
Node коробка передач / гидросистема
