The horizontal hinge bushing 125.30.138 is installed in two pieces inside the housing 151.30.018-3 (151.30.028) and is an important element of the frame articulation unit of the HTZ wheeled tractors. A pipe 151.30.046-3A (151.36.014A is a support with a pipe) passes through the bushings, ensuring mobility and proper operation of the hinged connection of the semi-frames.
The original bushings produced by the Kharkov Tractor Plant are characterized by increased wear resistance and have an elliptical shape, which helps to distribute the load evenly, reduce backlash and increase the service life of the horizontal hinge assembly.
The part is used on wheeled tractors HTZ T-150K, T-151K, T-156, HTZ-17221, HTZ-242, HTZ248, as well as on other wheeled HTZ models with a similar frame design.
The original bushings produced by the Kharkov Tractor Plant are characterized by increased wear resistance and have an elliptical shape, which helps to distribute the load evenly, reduce backlash and increase the service life of the horizontal hinge assembly.
The part is used on wheeled tractors HTZ T-150K, T-151K, T-156, HTZ-17221, HTZ-242, HTZ248, as well as on other wheeled HTZ models with a similar frame design.
-
Chassis type колесный
-
Applicability by brand ХТЗ
-
Number of uses in a unit/technique 2 pcs
-
Installation location труба
-
Catalog number 125.30.138А
-
Node рама
