Axle 151.30.137-1 (set with bushings)

2 500 грн.

Product code: CN1486-2

In stock

Weight: 0 kg.

The axle and bushings of the vertical hinge of the frame of the T-150 wheeled tractor, originally produced by HTZ, are included in an important connection point between the front and rear parts of the frame, ensuring mobility and stability of the structure when working on uneven surfaces. This set is also often referred to as "semi-frame pins and bushings".

Set contents:

Axle 151.30.137-1 – 2 pcs.
High bushing 125.30.136 – 2 pcs.
Small bushing 151.30.164 – 2 pcs (can be equipped with two standard ones and two with a cutout for a stopper 151.30.145-1)

The bushings and axles are made of hardened steel, which ensures their high wear resistance and load resistance. Cut-out bushings are generally not hardened, but they provide a more secure fit in the body when using a stopper.

All parts are original, produced by HTZ. At the customer's request, the kit can be supplemented with analogues that fully comply with the technical specifications. It is also additionally recommended to purchase washers 125.30.140, which are involved in assembly and adjustment of gaps.

Used on tractors T-150K, HTZ-17221, HTZ-242K, HTZ-248K and other models with an articulated frame.
