Fork 01M-2126 (catalog number 60.21.109) is designed to engage and disengage the clutch of the SMD-60 engine and is installed in the clutch housing of HTZ tractors. This is a key element of the clutch control mechanism, ensuring the transmission of force from the drive to the release bearing.
The fork is attached to the clutch release shaft 151.21.231-2 using two bolts and operates inside the clutch housing 151.21.201-3 (the assembled unit has the number 151.21.021-3, includes bushings, levers and other elements). When you press the clutch pedal with the fork, the release bearing 01M-21s9 moves, ensuring the clutch discs are disconnected.
The part is made of durable alloy steel, designed for high loads and long-term operation.
It is used on HTZ tractors with SMD-60 engines and similar clutch units, including models T-150, T-151, T-156 and other modifications.
The fork is attached to the clutch release shaft 151.21.231-2 using two bolts and operates inside the clutch housing 151.21.201-3 (the assembled unit has the number 151.21.021-3, includes bushings, levers and other elements). When you press the clutch pedal with the fork, the release bearing 01M-21s9 moves, ensuring the clutch discs are disconnected.
The part is made of durable alloy steel, designed for high loads and long-term operation.
It is used on HTZ tractors with SMD-60 engines and similar clutch units, including models T-150, T-151, T-156 and other modifications.
-
Applicability by brand ХТЗ
-
Number of uses in a unit/technique 1 pcs
-
Installation location валик выключения / муфта главного сцепления
-
Catalog number 60.21.109 / 01М-2126
-
Node сцепление
-
Engine СМД-60
