The spring cup 125.21.213 is used in the SMD-60 clutch of HTZ tractors and is intended for installing and fixing the pressure springs of the clutch mechanism.
Used in conjunction with safety cup 150.21.239 to hold spring 150.21.210 between pressure plate 150.21.203-3 and clutch housing 150.21.202A. This connection ensures uniform pressing of the clutch elements and stable operation of the mechanism when transmitting torque.
The part is used in an amount of 20 pieces as part of the clutch housing assembly 150.21.022-2A.
Used on tractors HTZ T-150, T-150K, T-151, T-151K, T-156 and other models with SMD-60 / SMD-62 engines and a similar clutch design.
Used in conjunction with safety cup 150.21.239 to hold spring 150.21.210 between pressure plate 150.21.203-3 and clutch housing 150.21.202A. This connection ensures uniform pressing of the clutch elements and stable operation of the mechanism when transmitting torque.
The part is used in an amount of 20 pieces as part of the clutch housing assembly 150.21.022-2A.
Used on tractors HTZ T-150, T-150K, T-151, T-151K, T-156 and other models with SMD-60 / SMD-62 engines and a similar clutch design.
-
Chassis type колесный
-
Applicability by brand ХТЗ
-
Number of uses in a unit/technique 20 pcs
-
Installation location пружин / кожух муфты
-
Catalog number 125.21.213
-
Node муфта главного сцепления
