The release lever 236-1601095-B2 (clutch basket foot YaMZ-236 / YaMZ-238) is used in the clutch assembly and is supplied assembled. Designed to transmit force in the clutch release mechanism and correct operation of the basket when squeezing.
The assembly includes: pull-out lever 236-1601095-B2, lever fork axis 236-1601113, lock washer 312702-P29, thrust ring spring 236-1601273-A2, pull-out lever fork 236-1601108-B, adjusting nut forks 236-1601109-B and spring loop 236-1601275-A2. All elements are selected and designed to work together under high load conditions.
This unit is used in clutches of YaMZ-236 and YaMZ-238 engines installed on HTZ tractors, as well as on other agricultural, road and special equipment with a similar clutch design.
The assembly includes: pull-out lever 236-1601095-B2, lever fork axis 236-1601113, lock washer 312702-P29, thrust ring spring 236-1601273-A2, pull-out lever fork 236-1601108-B, adjusting nut forks 236-1601109-B and spring loop 236-1601275-A2. All elements are selected and designed to work together under high load conditions.
This unit is used in clutches of YaMZ-236 and YaMZ-238 engines installed on HTZ tractors, as well as on other agricultural, road and special equipment with a similar clutch design.
-
Applicability by brand ХТЗ
-
Number of uses in a unit/technique 4 pcs
-
Installation location диск ведомый в сборе
-
Catalog number 236-1601095-Б2
-
Node сцепление
