Repair Sleeve 150.41.252-1 is used in the Power Take-Off (PTO) Gearbox of HTZ tractors to restore the functionality of the PTO Drive Shaft 150.41.103-6. After installing the sleeve and completing the repair, the assembly becomes PTO Drive Shaft Assembly 150.41.055-2, allowing the shaft to be rebuilt without replacing it entirely.
The sleeve is installed inside the PTO Gearbox 150.41.011-4 and features internal splines that engage with the NSH-10V-3 right-hand rotation gear pump. This ensures reliable transmission of torque from the drive shaft to the hydraulic pump responsible for operating the tractor's hydraulic system.
Using Repair Sleeve 150.41.252-1 restores worn splines on the drive shaft, eliminates excessive play, and ensures dependable power transmission. During repair, it is also recommended to inspect the splines of Drive Shaft 150.41.103-6 and the NSH-10V-3 gear pump, as wear on the mating components can significantly reduce the service life of the rebuilt assembly.
The sleeve is used in the PTO gearbox of both HTZ wheeled and crawler tractors, including T-150K, T-150G, T-151K, and other models equipped with the same PTO drive system.
-
Chassis type wheeled/tracked
-
Applicability by brand HTZ
-
Number of uses in a unit/technique 1 pcs
-
Installation location drive shaft
-
Catalog number 150.41.252-1 / 150.41.252
-
Node power take-off shaft
