PTO Control Cable Bracket 151.41.022-1 is used in the Power Take-Off (PTO) control mechanism of HTZ tractors and is designed to securely support the PTO Control Cable Assembly 151.41.013-2. The bracket ensures the correct positioning of the control cable, prevents movement during operation, and provides accurate transmission of force from the PTO control lever to the PTO engagement mechanism.
One PTO Control Cable Bracket 151.41.022-1 is installed on each tractor. It is secured using M10×20 bolts and 10.65G spring lock washers, ensuring reliable fastening even under vibration. The assembly also includes Cab Bracket 151.41.015-3, which supports and guides the control cable, ensuring proper routing along its entire length.
Properly functioning cable brackets help prevent cable misalignment, reduce stress on the cable housing, and ensure smooth PTO engagement and disengagement. During maintenance or repair of the PTO control mechanism, it is recommended to inspect both brackets, the mounting hardware, and the control cable itself. If any deformation, cracks, or other damage are found, the affected components should be replaced to maintain reliable PTO operation.
PTO Control Cable Bracket 151.41.022-1 is compatible with HTZ T-150K, T-151K, T-156, HTZ-17021, HTZ-17221, HTZ-242K, HTZ-248K, and other HTZ tractor models equipped with the same PTO control mechanism.
