Screw-in elbow 151.37.065 is used in the hydraulic system of the hitch and transmission units of HTZ tractors, providing a tight connection of hydraulic lines and hoses with body parts.
Consists of an angle 151.37.550, a nut M20.5915 and an o-ring 018-022-25-2-2.9833. In the hydraulic system of the attachment, a hydraulic cylinder is connected to a hose 150.61.020-06 leading to the hydraulic distributor R-80. In the transfer case assembly, it connects the cover 151.37.333-1 with the hose 150.08.023B-01, ensuring the supply of working fluid and the tightness of the connection.
A total of 3 pieces are installed on the tractor.
Used on tractors HTZ T-150, T-150K, T-151, T-151K, T-156 and other models with a similar hydraulic system and transfer case design.
Consists of an angle 151.37.550, a nut M20.5915 and an o-ring 018-022-25-2-2.9833. In the hydraulic system of the attachment, a hydraulic cylinder is connected to a hose 150.61.020-06 leading to the hydraulic distributor R-80. In the transfer case assembly, it connects the cover 151.37.333-1 with the hose 150.08.023B-01, ensuring the supply of working fluid and the tightness of the connection.
A total of 3 pieces are installed on the tractor.
Used on tractors HTZ T-150, T-150K, T-151, T-151K, T-156 and other models with a similar hydraulic system and transfer case design.
-
Applicability by brand ХТЗ
-
Number of uses in a unit/technique 3 pcs
-
Installation location крышка раздаточной коробки / гидроцилиндр
-
Catalog number 151.37.065
-
Node раздаточная коробка / гидросистема навесного оборудования
