Washer 151.37.330
Washer 151.37.330 is one of the key parts of the gear assembly 151.37.046-4Рz=19x30a new model, designed for installation on the input shaft of the transfer case of HTZ tractors (models T‑150, T‑151K, T‑156, etc.).
Role and features:
-
Installed complete withgear 151.37.046-4Рwhich runs on two bearings 502111L (8328, N1011M).
-
Together with bushing 151.37.321-1, the washer ensures reliable positioning and axial fixation of the components inside the gear.
-
Performs the function of compensating axial loads, eliminating play and displacement of the unit during rotation.
Application:
-
It is used in the transfer case of the new model, in particular in the assembly where the gear is installed on the shaft 151.37.305-4.
-
It is similarly equipped in systems that replace the old gear 151.37.046-3 (sleeve version) with a modernized bearing version.
Washer 151.37.330 is a small detail, but extremely important. Without it, full assembly and correct operation of the unit with a new type of bearing gear connection, which provides increased service life and resistance to loads, is impossible.
-
Number of uses in a unit/technique 1 pcs
-
Catalog number 151.37.330
