The brake chamber diaphragm of the T-150 tractor under catalog numbers 100-3519150 or 500-3519050 is installed inside the brake chamber 500-3519010-01, which is part of the pneumatic braking system of HTZ wheeled tractors. Also, such diaphragms are used on ZIL trucks with a similar brake system design.
The diaphragm design is an elastic element that perceives air pressure and converts it into mechanical force on the brake chamber rod. The quality of work directly depends on the material of manufacture:
– Rubber density
– Quality of reinforcement (internal stitching with threads)
– GOST compliance
There are two main modifications according to GOST: TYPE-16 and TYPE-20.
The correct choice of the type and quality of the diaphragm affects the braking efficiency and safety of equipment operation.
