Drum 151.38.114-2 is an important element of the wheel braking system of the HTZ tractor, providing reliable braking and holding the machine when stopping. Installed in the amount of 4 pieces per tractor - two each on the front and rear axles.
The drum interacts with the internal components of the brake assembly, including:
Mounted on top of the drum:
Made from durable cast material, providing resistance to high loads, friction and overheating. The geometry of the drum is maintained with high precision, which contributes to uniform pressing of the pads and the absence of beats during braking.
Used on HTZ tractors, such as:
T-150, T-150K, HTZ-17221, HTZ-17222, HTZ-181, HTZ-200, HTZ-242 and their modifications.
The drum interacts with the internal components of the brake assembly, including:
- Brake pads - 151.38.049 and 151.38.049-1,
- Brake knuckle bracket,
- Expanding fist - 151.38.208 / 151.38.209,
- Adjustment lever (ratchet) - 120-3501136.
Mounted on top of the drum:
- Brake protective shield,
- The wheel rim also serves as protection against external contamination.
Made from durable cast material, providing resistance to high loads, friction and overheating. The geometry of the drum is maintained with high precision, which contributes to uniform pressing of the pads and the absence of beats during braking.
Used on HTZ tractors, such as:
T-150, T-150K, HTZ-17221, HTZ-17222, HTZ-181, HTZ-200, HTZ-242 and their modifications.
-
Chassis type колесный
-
Applicability by brand ХТЗ
-
Number of uses in a unit/technique 4 pcs
-
Catalog number 151.38.114-2
-
Node тормоз колесный
