Crankshaft pulley 60-04106.10 is one of the key elements of the drive of attachments of the SMD-60 engine, installed on tractors KhTZ: T-150, T-151, T-156and other models.
The pulley is secured to the crankshaft 60-04101.20 (assembled 60-04008.00) using a lock washer 60-04109.10and ratchet 60-04107.10, which guarantees reliable fixation and eliminates rotation when the engine is running.
The crankshaft pulley serves to transmit torque from the crankshaft to engine components through V-belts. In the design of the SMD-60 engine, the following operation is ensured through this pulley:
-
cooling system water pump,
-
generator,
-
compressor (on versions with pneumatic system).
Thus, the crankshaft pulley is the central element of the entire belt drive system, synchronizing the operation of auxiliary units with engine speed.
Design and features:
-
Made from durable cast iron or steel, designed to withstand long-term dynamic loads.
-
Works with standard profile V-belts (for example,A-1120 16x11x1120to drive the compressor or similar belts for the generator and water pump.
-
Has grooves for one or more belts, depending on the engine configuration and installed equipment.
Used as part of the SMD-60/62engine, installed on:
-
HTZ tractors: T-150, T-151, T-156,
-
as well as on other equipment with this type of diesel engine.
-
Catalog number 60-04106.10
-
Engine СМД-60
