The air filter cartridge 60-12028.00 / 60-12029.00 is a set of replaceable filter elements used in the air purification system of KhTZ tractors and DON combines equipped with SMD-60 engines. The kit includes two filters: a larger external filter - 60-12029.00 and a smaller internal filter - 60-12028.00. Together they make up the second (fine) stage of air purification.
Installed inside housing 62-12004.00, which is part of air cleaner 62-12002.00. Primary air purification is carried out using a monocyclone 60-12023.00, which traps large particles of dust and contaminants. The air then passes through this filter cartridge unit, protecting the engine from fine dust and extending the service life of the cylinder-piston group.
Filter cartridges of this type are widely used on tractors T-150, T-150K, KhTZ-17221, KhTZ-17222, KhTZ-21021, as well as on grain harvesters of the DON series.
Installed inside housing 62-12004.00, which is part of air cleaner 62-12002.00. Primary air purification is carried out using a monocyclone 60-12023.00, which traps large particles of dust and contaminants. The air then passes through this filter cartridge unit, protecting the engine from fine dust and extending the service life of the cylinder-piston group.
Filter cartridges of this type are widely used on tractors T-150, T-150K, KhTZ-17221, KhTZ-17222, KhTZ-21021, as well as on grain harvesters of the DON series.
-
Applicability by brand ХТЗ / ДОН
-
Number of uses in a unit/technique 1 pcs
-
Installation location воздухоочиститель
-
Catalog number 60-12028.00 / 60-12029.00
-
Node система очистки воздуха
-
Engine СМД
