Radiator mesh latch 150.47.063-1A
Code:
CN1240
Available
Radiator mesh latch 150.47.063-1A
Имя:
Телефон: *
Email: *
Комментарий:
Latch 150.47.063-1A is an element of the tractor facing assembly that provides reliable fixation of the front protective mesh of the radiator 150.47.023-4 / 170.47.023. It is installed in the upper part of the radiator guard 150.47.011-6 / 150.47.011-6-02 / 150.47.011-6-04 / 170.47.011-1 and prevents spontaneous opening of the mesh during vibrations and increased loads.
The latch design includes:
Used on HTZ tractors of various modifications:
T-150, T-151, T-156, HTZ-17221, HTZ-17222, HTZ-242K, HTZ-248K and other models with a similar radiator lining assembly.
The latch design includes:
- latch 150.47.335,
- housing 150.47.062-1A,
- spring 150.47.336,
- axle 150.47.337,
- set of fastening elements - bolts, washers and cotter pins.
Used on HTZ tractors of various modifications:
T-150, T-151, T-156, HTZ-17221, HTZ-17222, HTZ-242K, HTZ-248K and other models with a similar radiator lining assembly.
-
Applicability by brand HTZ
-
Number of uses in a unit/technique 1 pcs
-
Installation location radiator mesh / hood
-
Catalog number 150.47.063-1A
-
Node cladding
